CAPACITY:

X-Axis Travel 62.99"
Y-Axis Travel 31.49"
Z-Axis Travel 27.95"
Table Size 70.86" x 31.49"
Table Weight Capacity 4,400 lbs
Spindle Speeds 10,000 RPM
Spindle Taper #50 ISO
Spindle Nose to Table 5.9"/33.85"
Spindle Drive Motor 20 HP / 26 HP
Electrics 220/3/60
Machine Dimensions (w/ Chip Conveyor) . 210" x 123" x 119"Machine Weight 24,500 lbs

Equipped With:

Fanuc 31iMB CNC Control
Fanuc Spindle & Axes Servo Motor Package
Telescopic Way Covers For X & Y Slide Ways
Rigid Tapping
Coolant Thru Spindle (70 Bar)
Box Ways
32-Position Automatic Tool Changer
Automatic Lubrication System
Fully Enclosure Splash Guards
Chip Conveyor

Note:


Brand New Machine, Approx. 5-Month Delivery
1-Year Parts Warranty on Machine
2-Year Parts & Labor On CNC Control
