CAPACITY:

Maximum Power.......................... 6000 Watts 6000 Watts
Maximum Sheet Size 60.04" x 120.08"
X-Axis Travel 122.05"
Y-Axis Travel 62.80"
Z-Axis Travel 4.33"
Work Table Height 35.43"
Max. Cutting Thickness (Mild Steel) 1.00"
Max. Cutting Thickness (Stainless) 1.00"
Max. Cutting Thickness (Aluminum) .750"
Maximum Load Capacity 2,050 Lbs.
Rapid Travels (X/Y Axis) 4,724 IPM
Installation Dimensions 394" x 240"
Machine Unit Dimensions 334" x 137" x 79"
Machine Weight 33,069 Lbs.

Equipped With:

MAZATROL PREview 3 CNC Control with 19" Color LCD Touch Monitor
6 KW IPG Photonics YLS-6000 Resonator
Helical Rack and Pinion Drives on X and Y Axes
MCT-2.0 Upgraded Cutting Head
Auto Nozzle Changer and Cleaner
Automatic Dual Pallet Changer
Chiller
Robovent Plaser Dust Collector

Note:


Inspect in Plant Under Power
