CAPACITIES:

Quill Diameter 5.51"
Ram Cross Section 14.96" x 15.74"
Spindle Taper #50 ISO
Spindle Speeds, Variable (2) Step 2,500 RPM
Vertical Travel of Head, Y-Axis 125.98"
Horizontal Column Travel, X-Axis 314.96"
Ram Travel, Z-Axis 31.49"
Quill Travel, W-Axis 27.55"
Total Axial Travel 59.05"
Feeds X/Y/Z/W Axes 196 IPM
Rapids X/Y/Z/W Axes 393 IPM
Spindle Motor 49 HP / 60 HP

Equipped With:

Fanuc 31i-MB CNC Control
60-Station Automatic Tool Changer
Coolant Through Spindle
Precision Ground Ballscrews
Heavily Ribbed Cast Iron Components
Hardened Box Ways on Y-Axis Column
Roller Type Linear Guide ways with Rack and Pinion on X-Axis
Telescopic Way Covers
CE Declaration of Conformity for EU Countries
