48" x 6.00" x 20,000# Paxson/Wean Slitting Line STOCK# 3451
Brand
Not specified
Category
Model
Not specified
Stock #
3451
Year
Not specified
Condition
Good
Location
Ohio
|
48" x 6.00" x 20,000# Paxson / Wean Slitting Line
Consisting of: -Uncoiler: Nova Hydraulic Expansion Sliding Base Threading Drive Holddown Roll Wichita Brake -Peeler Table: -Slitter Head: Wean 6" Dia. Arbors Entry Side Guides Entry Pinch Rolls AC Motor Threading Drive -Scrap Baller: Auto Scrap Eject AC Drive Motor -Tension Stand: Nova Drag Wipe Type Entry Separator Tooling Bar Exit Passline Roll -Recoiler: Paxson 20" Dia. x 52" Face Drum Manual Clamp and Expansion Hydraulic Pushoff Overarm Separator 64" O.D. Max. 50 HP Reliance DC Motor, 850/2550 RPM, 500 V, w/Blower Foote Brothers Reducer w/31.4:1 ratio, rated at 76.5 HP at 1750 RPM IN Self-Contained Hydraulic Power Unit, 5 HP AC Motor Passline: 41" from Floor to Center of Drum Overall Size: 213" L x 62" W x 69" High -Exit Coil Car: Revolvator Self-Contained Hyd. -Slitter Tooling: -Line Direction: Left To Right |
