FORMING TONNAGE .............................. 17-1/2"
DISTANCE BETWEEN JAWS:
Max Length of Part Tension Cylinders retracted..... 205" (5207mm)
Min Length of Part Tension Cylinders extended....... 10" (254 mm)
TENSION CYLINDER PULL:
Maximum............................ 35,000 lbs.
Minimum ............................ 3,500 lbs.
@ Operation PSI..................... 2,000
TENSION CYLINDER STROKE each ....... 18-1/2"
TENSION CYLINDER ROTATION .......... +/- 25 Degrees
ARMS: SWING Simultaneous Arm Motion
Arm swings 10 Forward to 90Back.
WRAPPING SPEED RANGE ............... Adjustable
DIE LENGTH at full tonnage and 180 bend:
Minimum .................................. 20" (508 mm)
Maximum ................................. 68" (1727.2 mm)
DIE TABLE: (Pre drilled & threaded) .... 5/8"
Working Surface, W x D............... 65" x 30" (1651 x 762 mm)
Height Table To Floor ................. 35" (889 mm)
MOTOR DRIVE: Wired 440 volts, 3 Phase
Hydraulic Pump ............................15 H.P. 220/440 volts
CONTROLS: Hand Push Buttons, with Start and Stop Buttons
EQUIPPED WITH:
1- set 4x6 Jaws with Hydraulic Clamping
1- lot misc. dies COMPLETE FACTORY SAFETY GUARDS
Dimensions 65 w x 170" d x 55" Ht Wt 12000 lbs. |
