3 HP COMET RAM TYPE VERTICAL MILL: STOCK #76559
Brand
Category
Type
Model
null
Stock #
76559
Year
Not specified
Condition
Not specified
Location
Ohio
|
SERIAL ................................... 1260 MODEL .................................... 3-VHG AREA OF TABLE ............................ 9" X 42" LONGITUDINAL TABLE TRAVEL ................ 30" CROSS TABLE TRAVEL ....................... 16" VERTICAL KNEE TRAVEL ..................... 16" QUILL TRAVEL ............................. 5" RAM TRAVEL IN/OUT ........................ 24" SPINDLE SPEEDS VARIABLE SPEED ............ 60 TO 4,200 RPM SPINDLE TAPER ............................ R-8 POWER QUILL FEEDS ........................ 0015, .003 & .006 IPR POWER DRAWBAR ........................... YES POWER LONGITUDINAL TRAVEL ................ YES DISTANCE, SPINDLE NOSE TO TABLE .......... 2" MINIMUM 18" MAXIMUM DISTANCE SPINDLE CENTERLINE OF COLUMN .... 4" MINIMUM 28" MAXIMUM HEAD TILTS ............................... 45 DEGREES (BACK & FORWARD) HEAD ROTATES ............................. 90 DEGREES (RIGHT & LEFT) MOTOR .................................... 3 HORSEPOWER |
