6" x 6" x 1/2" Scotchman Hydraulic Ironworker DO 120/200-24M, 120 Ton, Dual Operator, New

Model
DO 120/200-24M
Stock #
31328
Year
Not specified
Condition
New
Location
South Dakota
(NEW) SCOTCHMAN HYDRAULIC IRONWORKER

MODEL: DO 120/200-24M

STANDARD FEATURES

Dual Operator Allows For Two Operators To Work At The Same Time At Full Capacity
Five Stations
120 Ton Punch Station (1-1/2" In 1")
Keyed Punch Ram For Safety
12" Throat Depth
Punch Gauging Table With Fence and Scale
Die Holder Complete With 2" and 2-1/2" Die Inserts
Punch Nut With Wrench and Stripper
Adjustable Swing-Away Stripper
One Round Punch & Die: Maximum 1-1/4" Diameter
Punch Jog Control
Two Adjustable Electric Stroke Controls With Scale
Two Electric Remote Foot Pedals
Two 2-Stage Hydraulic Pumps
Two Valves
Rectangle Notcher: 3" x 5-3/4" x 1/2"
Notcher Table With Guides
200 Ton, 24" Flat Bar Shear With Saber Blade
Shear Table With Miter Fence
Tool Table Work Area
Slug Receptacles
Electrical Box Supplied With Emergency Palm Button and Lock-Out
Tag-Out Accomodations
230/460 Volt/3 Phase Electrics (Must Specify Voltage)
All Guards Necessary To Comply With ANSI B 11-5 Standards
Forklift Accomodations
ThreeYear Warranty
Made In USA

CAPACITIES AND SPECIFICATIONS: Rated On: A 36 Mild Steel/65,000 psi Tensile

Punching Capacity: 120 Ton, 1-1/2" In 1"
Special Tooling: 4" Maximum Diameter
Throat Depth: 12
Flat Bar Shear, 200 Ton, 24" Length
 1" x 12"
 3/4" x 20"
 1/2" x 24"
Angle Shear, 90 Degrees: 6" x 6" x 1/2"
Angle Shear, 45 Degrees: 4" x 4" x 1/2"
Brake 12"*: 75 Ton
Brake 24"*: 55 Ton
Open End Brake: Maximum 1/4" x 5" Flat or Angle Iron
Pipe Notcher, Schedule 40 I.D.*: 3/4", 1", 1-1/4, 1-1/2", 2"
Rectangle Notcher: 3" x 5-3/4" x 1/2"
V-Notch: 3" x 3" x 1/2"
90 Degree V-Notcher*: 6" x 6" x 5/16"
Notching In Leg Of Channel: 6" to 10"
Channel Shear: 2" to 6" Adjustable
Rod Shear*
Round Rod: 1/4" to 1-1/4", 9 Cavity
Square Rod: 1/4" to 1", 1 Cavity
Square Tube Shear*: 1/2" to 2", 12 Gauge
Picket Tool Housing*: 1/2", 3/4", 1", 16 Gauge
Offset Die Holder: Maximum 40 Ton
Strokes Per Minute, Light Material, 1/4" Stroke: 47 SPM
Strokes Per Minute, Heavy Material, 3/4" Stroke: 16 SPM
Hydraulics: 3500 PSI
Standard Motor: 10 HP, 3 Phase 230/460/208//380/575 V
Optional Motor: 10 HP, 1 Phase 230 V

*Optional Equipment Available

Dimensions: 34"W x 77"L x 74"H
Approximate Weight: 6200 Lbs.

F.O.B. Philip, South Dakota

FACTORY SPECIFICATIONS, SUBJECT TO CHANGE AND/OR MODIFICATION
