BLANKHOLDER CAPACITY............................... 90 TONS
STROKE ......................................... 11-1/2
SHUTHEIGHT (ON BED ADJUSTMENT UP)............... 24"
SHUTHEIGHT (ON BED ADJUSTMENT DOWN)............. 20"
PLUNGER CAPACITY .................................. 122 TONS
STROKE ......................................... 20"
SHUTHEIGHT (ON BED ADJUSTMENT UP)............... 26"
SHUTHEIGHT (ON BED ADJUSTMENT DOWN)............. 22"
BED AREA ..........(L-R) x (F-B) .................. 26" X 28-1/2"
RAM AREA ..........(L-R) x (F-B) .................. 20" X 19-3/4"
BOLS6TER AREA .....(L-R) x (F-B) x (THICK) ........ 25-3/4" X 28-3/16" X 3"
RAM PLATE .........(L-R) x (F-B) x (THICK) ....... 18-1/4" X 18-1/4"
X 2-3/16"
SIDE FRAME OPENING ................................ 10-7/8"
WIDTH BETWEEN UPRIGHTS ............................ 26"
O.A. DIMENSIONS ...(L-R) x (F-B) x (HIGH).......... 6'3" X 8' X 12'6"
WEIGHT ............................................ 28000 LBS.

EQUIPPED WITH: AIR CLUTCH
STRAIGHT SIDE TYPE FRAME
SINGLE BACK GEARED
CENTRALIZED GREASE GUN LUBE
PALM BUTTONS
WINTRISS CLUTCH AND BRAKE CONTROL
DIRECT V-BELT MOTOR DRIVE
15 HP 3/220-440/60 (1755 RPM) MOTOR WITH CONTROLS
