STROKE ............................ 10"

RATED CAPACITY .................... 200 TONS

BED AREA .......................... 36" F-B X 31-1/2" L-R (NO BOLSTER)

WINDOW ............................ 18"

SPM ............................... 30

SHUTHEIGHT ........................ BOLSTER 17"
BED 22"

CUT OUT HOLE IN BED ...............23" x 23"

AIR CLUTCH AND BRAKE

TIE ROD FRAME

WINDOW MOUNTED COUNTER BALANCE

WEIGHT ............................ 50,000 LBS.EST.
O.A. DIMENSIONS ................... 7'10"W X 7'10L


EQUIPPED WITH: AIR CLUTCH
H TYPE FRAME
20 HP 460 VOLT 1130 RPM
TWO (2) AIR TANKS
CONTROLS MOUNTED ON ELECTRICAL CABINET
ONE E STOP MOUNTED
