RATED CAPACITY ......................... 260 Tons
STROKE ................................. 4"
MAXIMUM ADJUSTMENT ..................... 6"
DEPTH OF THROAT RAM CENTER TO FRAME .... 12"
RAM .................................... 12'
WIDTH BETWEEN UPRIGHTS ................. 8'6"
MAXIMUM DIE SPACE ...................... 14"
THROAT ................................. 10-1/2"
PIT DEPTH .............................. 30"
BED LENGTH ............................. 144"
BLADE WIDTH ............................ 4"
O.A. DIMENSIONS ....(LR X FB X HIGH).... 12'4" X 8'4" X 11'
WEIGHT (APPROX): 42,000 LBS
EQUIPPED WITH: AIR CLUTCH AND BRAKE
MOTORIZED RAM ADJUSTMENT
25 HP, 220/440V, 3/60/1800 RPM W/CONTROLS
AUTO LUBE
PALM BUTTONS
|
