MANUFACTURER: MORGAN/DAIDO
AGE: 1990
QUANTITY: ONE MILL, THREE STANDS
GENERAL SPECIFICATIONS:
TYPE : 2 HORIZONTAL - 1 VERTICAL
MOUNTED ON COMMON BASE
2 HIGH ON 26.4" CENTERS (670 MM)
CAPACITY : 1-3/8" TO 3-1/2" BAR
SPEED : 200 TO 700 FPM
HOUSING : CLOSED TOP (SPECIAL)
WELDED STEEL FRAME
ROLLS : 312 MM MIN. TO 350 MM MAX. x 130 MM FACE
REDUCTION
RATIOS : 4% TO 12%
TOLERANCE : +/- 0.2% OF DIAMETER OR 0.10 MM
BEARINGS : 4 ROW CYLINDRICAL
PREVIOUS USE : BAR MILL SIZING MILL
FEATURES * 6 SPINDLES (4 H/ 2 V) WITH GERA-TYPE COUPLING
* STEEL HOUSING LEVERS
* FRONT AXIAL ADJUSTMENT FOR ROLL ALIGNMENT
* SPARE SET UP STAND AND ROLLS
* AVTRON DIGITAL CONTROL (1998)
DRAWING AVAILABLE |
