330 Ton X 8’ Straight Side Double Crank Press with Slide Guided by Eight Full-Length, Ninety-Degree Gibs with Nickel-Bronze Wear Plates, Offering Maximum Control, a High Degree of Accuracy and Ease of Adjustment.

GENERAL SPECIFICATIONS

  • Capacity (US Tons): 330 Tons
  • Bed Area : 98.43" LR x 55.12" FB
  • Working Height To Top of 7" Bolster: 39.37"
  • Stroke Length: 10.12"
  • Shut Height: 30.12"
  • Speed: 30-60 SPM
  • Ram Adjustment: 8.27"
  • Windows: 34.75" Wide x 27.50"H
  • Approx Dimensions (Top Of Press): 150"LR x 118"FB x 180"H
  • Approx. Weight: 145,000 LBS

INCLUDES: Eight Full-Length, Ninety-Degree Gibs with Nickel-Bronze Wear Plates, Offering Maximum Control, a High Degree of Accuracy and Ease of Adjustment.

***We strongly encourage personal inspection of all pieces of used equipment***
***All Price, Location and Specifications Subject to Change without Notice***
