12" X 28" SOUTH BEND/ CHEVILIER FSG-1228AD SURFACE GRINDER: STOCK #81072

html

SERIAL ........................................ 37481M

MODEL ......................................... FSG-1228AD

MAGNETIC CHUCK ................................ 12" X 28"

GRINDING CAPACITY ............................. 12" W X 28" L

HEIGHT FROM TABLE SURFACE TO SPINDLE CENTER ... 19-3/4"

LONGITUDINAL TRAVEL ........................... 29-1/2"

LONGITUDINAL TRAVEL SPEEDS .................... 16 TO 82 FPM (VARIABLE)

CROSS TRAVEL .................................. 12"

CROSS TRAVEL FEED, AUTOMATIC .................. 1/8" TO 2" INCREMENT

INCREMENTAL DOWNFEED, AUTOMATIC ............... .00005" TO .002" INCREMENT

STANDARD GRINDING WHEEL ....................... 14" OD X 2" W X 5" ID

SPARK-OUT ..................................... YES

ROLLER BEARINGS ............................... YES

TABLE CAPACITY ................................ 946 LBS

CONTROL ....................................... MICROPROCESSOR

HEIDENHAIN DIGITAL DISPLAY .................... YES

COOLANT SYSTEM WITH PAPER FILTER .............. YES

SPINDLE MOTOR ................................. 5 HP
