2,200Lbs Capacity Welding Positioner with T-Grooves, Adjustable Rotating Speed, Mechanical Angle Indicator, Welding - Grounding Mechanism, Height Adjustment Capability and Digital Speed Indicator

GENERAL SPECIFICATIONS
Carrying Capacity:                        2,200 Lbs
Max Frontal Loading Center:                5.9”
Max Side Loading Center:                    5.9”
Max Table Tilting:                        0 - 115°
Rotation Motor:                        0.74 HP
Hydraulic Unit Motor:                    1.5 HP
Table Rotation Speed Min / Max:                0.1 - 0.9 RPM
Table Diameter:                        35.4”
T - Slots (Number - Angle):                6 - 60
Overall Length:                        94.5”
Min. Horizontal Table Height:                36.6”
Max. Horizontal Table Height:                65”
Height of Horizontal Rotation:                28.3”
Width of Machine:                        35.4”

INCLUDES: T-Grooves, Adjustable Rotating Speed, Mechanical Angle Indicator, Welding - Grounding Mechanism, Height Adjustment Capability and Digital Speed Indicator

***We strongly encourage personal inspection of all pieces of used equipment***
***All Price, Location and Specifications Subject to Change without Notice***
