250 TON X 12' ACCURPRESS MODEL 7250-12 HYDRAULIC PRESS BRAKE: STOCK #80647

SERIAL ........................................... 575

MODEL ............................................ 725012

CAPACITY ......................................... 250 TON

OVERALL LENGTH OF BED & RAM ...................... 12'

DISTANCE BETWEEN HOUSING ......................... 10'6"

STROKE ........................................... 8"

OPEN HEIGHT ...................................... 16"

CLOSED HEIGHT .................................... 8"

STROKES PER MINUTE ............................... 13 FULL STROKE

THROAT ........................................... 10"

RAM SPEED (FAST APPROACH) ........................ 55 IPM

RAM SPEED (SLOW BEND) ............................ 15 IPM

RAM SPEED (FAST RETURN) .......................... 130 IPM

ADJUSTABLE BOTTOM DIE HOLDER ..................... YES

BACK GAUGE ....................................... 27"

OPERATOR STATION ................................. YES

ELECTRIC FOOT PEDAL .............................. YES

MOTOR, HORSEPOWER ................................ 20
