12" X 24" KENT MODEL KGS 63AHD HORIZONTAL SURFACE GRINDER: STOCK #80593
Brand
Category
Model
KGS 63MS1
Stock #
80593
Year
Not specified
Condition
Not specified
Location
Not specified
|
SERIAL ................................ 98106602 MODEL ................................. KGS-63AHD YEAR NEW .............................. 1998 GRINDING CAPACITY ..................... 24" X 12" SPINDLE CENTER TO TABLE (MAX.) ........ 24" LONGITUDINAL TABLE TRAVEL ............. 28" CROSS TABLE TRAVEL .................... 13.4" ELECTRO-MAGNETIC CHUCK SIZE ........... 34" X 12" TABLE SPEED (VARIABLE) ................ 16 TO 82 FPM GRINDING WHEEL SIZE ................... 14" X 1-1/2" X 5" SPINDLE SPEED ......................... 1740 RPM POWER ELEVATION ....................... YES AUTO INCREMENTAL DOWNFEED ............. YES AUTO CROSS FEED ....................... YES TOUCH PAD CONTROLS .................... YES ELECTRO-MAGNETIC CHUCK W/CONTROLS ..... YES COOLANT WITH MAGENETIC SPERATOR ....... YES AUTO LUBE SYSTEM ...................... YES 2 AXIS DIGITAL READOUTS ............... MITUTOYO SPINDLE MOTOR ......................... 5 HORSEPOWER HYDRAULIC MOTOR ....................... 1-1/2 HORSEPOWER |
