14' X 3/8" CINCINNATI MODEL 375-HS HYDRAULIC SHEAR WITH BACK GAUGE; FLOOR STANDING, NEW 1998: YOBRO #24238

Name: Used CINCINNATI 375 HS For Sale 24238
Brand: CINCINNATI
SKU: 24238
Availability: PreOrder

Brand

CINCINNATI

Ohio

Dimensions	222" L-R x 109" F-B x 99" H
Weight	32500 pounds
SERIAL .............................. 50899 NEW ................................. JUNE 1998 MODEL ............................... 375HSX14' CAPACITY ............................ 14 FT. X 3/8" MILD STEEL TYPE ................................ FLOOR STANDING (NO PIT) LENGTH OF KNIVES .................... 172" RAKE ANGLE .......................... 7/16" DISTANCE UNDER HOLDDOWNS ............ 5/8" NUMBER OF HOLDDOWNS ................. 17 FORCE OF HOLDDOWNS .................. 1925 TONS SPEED, SPM .......................... 7 TO 41 FLOOR TO TOP OF BED ................. 36" FRONT OPERATED BACK GAUGE ........... 48" PUSHBUTTONS ......................... FAST/SLOW-REVERSE/READOUT SQUARING ARM ........................ 12' NUMBER OF STOCK SUPPORT ARMS ........ 2 ELECTRIC FOOT SWITCH ................ YES START / STOP PUSH BUTTONS ........... YES UP /DOWN SELECTOR SWITH FOR GAUGE ... YES STROKE COUNTER ...................... YES KEY SELECTOR SWITCH ................. INCH/OFF/SINGLE STROKE/CONTINUOUS TRANSFER BALLS (TOP OF TABLE) ....... YES (6) DOVETAIL SLOTS (TOP OF BED) ..... YES DOVETAIL SLOT (FRONT OF BED) ........ YES MATERIAL THICKNESS & LENGTH KNOBS ... YES REAR PARTS CHUTE .................... YES BACK GAUGE MOTOR .................... 1/2 HP HYDRAULIC PUMP MOTOR ................ 25 HP

Watch 14' X 3/8" CINCINNATI 375 HS POWER SQUARING SHEAR WITH BACK GAUGE; FLOOR STANDING: YOBRO #24238

Specifications
