Thiele BF400V Bliss Case Former for 3 Piece Bliss Cases, 2018

Used Thiele BF400V Bliss Case Former for 3 Piece Bliss Cases, 2018:

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Presently set up to run 3 piece bliss cases, 22-1/16″ x 14-5/8″ x 5-9/16″ at a rate of 20 bliss cases per minute

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Capable of being set up to run these case dimensions: Length: 9-1/4″ – 31-7/8″ Width: 8″ – 20″ Depth: 4″ – 16″

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Speeds from: 12-35 bpm depending on style and size

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Features: – Kwik-change crank adjustable bottom stops. – Standard body hopper – 100 blank capacity. – Vacuum feed system w/filter kit. – Single feed wheel. – Nordson ProBlue 15 glue system mounted to the Tray/Bliss frame. – Rail mandrel guide system. – Extended stroke feed post. – Internal flange which is 3-1/2 to 5-inches. – One forming mandrel (included). – Heavy duty mild steel / aluminum construction. – Thiele steel colored enamel paint. – Electrical service of 460 volts AC, 60 Hz, 3-phase. – Control voltage is 24 VDC. – Allen Bradley MicroLogix 1400 PLC with Ethernet. – PanelView Plus Compact 400 with color touch screen. – Variable frequency drive. NEMA 12 electrical construction. – Compressed air requirement is 80 PSI (5.5 bar).

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Safety Package, Including: – Interlocked polycarbonate access doors – Fixed guards and covers (require a tool to be removed) – Category 3 Safety circuit – One E-Stop – Lockable main disconnect (rotary style) – 2-color stack light (red/green) with audible start-up alarm – Lockable hand valve (air inlet)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
