17" x 80" YAM Lathe, Inch/Metric, 32-1800 RPM, Chucks

YAM ENGINE LATHE

MODEL: YAM-2000
SERIAL NUMBER: 8300123

GENERAL SPECIFICATIONS

Swing Over Bed: 17-1/8"
Swing Over Cross Slide: 9-3/4"
Distance Between Centers: 80"
Spindle Bore: 2-9/32"
Spindle Nose: D-1-6 Camlock
Spindle Speeds: (12) 32 - 1800 RPM
Inch Threads: 4 - 80 TPI
Metric Threads: 0.25 - 7mm
Feeds: (32)
Longitudinal Feeds: .045" - .627"
Cross Feeds: .0045" - .627"
Cross Slide Travel: 9-5/8"
Compound Rest Travel:5-7/8"
Tailstock Quill Diameter: 2-9/16"
Tailstock Quill Travel: 6"

EQUIPPED WITH

7-1/2 HP Motor
Inch/Metric Threading
Magnescale Two-Axis Digital Readout*
*Readout presently works, but because of the age is not covered under 30-Day return privilege.
10" 3-Jaw Chuck
Quick Change Tool Post w/Holders
Steady Rest
Thread Dial

Approximate Weight: 5000 Lbs.

F.O.B. Cincinnati, Ohio

ALL SPECIFICATIONS SUBJECT TO VERIFICATION BY PURCHASER
