Framecad F325iT Roll-Forming Machine, 2014

Machine Dimensions Length: 144″ Width: 31.5″ Height: 47.2″ Weight: 4,012 lb Decoiler capacity: 6,600 lb Coil OD: 48″ Max. Hydraulic Oil Pressure: 180 Bar Max. Oil Temperature: 65*C

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Profile & Material Capacity Profile width (web): 2.5″ to 6″ Standard profile size: 3.5″ Material thickness: 0.024″ to 0.047″

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Performance Max line speed: 5,740 ft/hr Typical output: 2,460 ft/hr Main drive power: 10 HP Hydraulic power: 7.4 HP Hydraulic reservoir: 17 gal Voltage: 400 VAC, 3-phase, 25 A

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Tooling & Features Roll-forming stations: 10 auto-gauging Punching tools (11 standard) Printer: Dual 16-point print heads Interface: 21.5″ touchscreen Software: FRAMECAD Detailer, ProDesign, Factory2 Hot-climate hydraulics: Optional for >104°F

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
