Axon ThermoPoint Shrink Sleeve Heat Tunnel System with Conveyor – Stainless, Inline, Electric

Equipment Overview

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Axon ThermoPoint stainless-steel steam shrink sleeve tunnel built with 3 independent zones, tool-less changeover, condensate control, and rated for up to 6″ W × 15″ H containers. Conveyor included; steam generator unknown. Supports full-body, partial-body, tamper band, and multipack applications with high consistency and repeatability.

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Key Features and Specifications – Stainless steel double-wall construction for external safety and durability – Three independently adjustable steam zones (height, rate, angle) – Tool-less changeover (Allen wrench) for container size flexibility – Condensate tray and steam evacuation flues to manage moisture and cleanliness – Suitable for containers ≤ 6″ wide × 15″ high – Steam input ≥ 80 psi; up to 200 lb/hr consumption (≈30 gal/hr) – Electrical: 115/230 VAC single-phase 50/60 Hz; blower motor ~½ HP – Approx weight ~1,200 lb; dimensions ~24″ W × 79″ L × 77″ H – Optional: requires external steam generator or inline builder

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
