Hennecke MicroLine 45 R/MT Polyurethane Machine, 2019 (1)

The Hennecke MicroLine series is designed for high-pressure metering of polyurethane (PU) components, particularly where small outputs and high precision are required. The MicroLine 45 R/MT is tailored for applications needing low shot weights

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,1 metering unit for Polyol with an HP 2 metering pump, max. nominal output approx. 54 cm3 /sec at 2.6 kW/1800 min-1

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,1 metering unit for Isocyanate with an HP 2 metering pump, max. nominal output approx. 54 cm3 /sec at 2.6 kW/1800 min-1

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,2 set of safety valves, electronic pressure indicators, on delivery and suction side; line system

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,1 machine support frame with integrated, removable collection troughs

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,1 hydraulic unit including pressure accumulator, valves and accessories

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,(in compliance with European Pressure Equipment Directive)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,2 low-pressure recirculation via frequency converter

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,1 MT-6, mixhead piston-cleaned

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,6 m of flexible lines to the mixhead

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
