SHARP MODEL UH-3 UNIVERSAL HORIZONTAL MILLING MACHINE: STOCK #80008

SERIAL .............................. 2H339

MODEL ............................... UH3

YEAR NEW ............................ 2020

AREA OF TABLE ....................... 51.18" X 11.81"

LONGITUDINAL TABLE TRAVEL ........... 37-3/8"

CROSS TRAVEL ........................ 14-13/16"

VERTICAL KNEE TRAVEL ................ 18-1/2"

RAM TRAVEL .......................... 15-1/2"

SPINDLE SPEEDS (VARIABLE) ........... 35 TO 1382 RPM

LONGITUDINAL & CROSS TABLE FEEDS..... 1/2 TO 24-7/8" IPM

LONGITUDINAL & CROSS RAPID TRAVERSE.. 116-1/2 IPM

VERTICAL KNEE FEEDS ................. 1/2 TO 12-7/16 IPM

TAPER IN SPINDLE .................... NMTB-50

SPINDLE CENTER TO TABLE SURFACE ..... 0" TO 18-1/2"

TABLE SWIVELS LEFT/RIGHT ............ 45 DEGREES

CHROME WAYS ......................... YES

AUTOMATIC LUBE ...................... YES

2 AXIS DIGITAL READOUTS ............. ACU-RITE

COOLANT ............................. YES

OVERARM SUPPORT ..................... YES

MOTOR ............................... 7.5 HORSEPOWER

NEW MACHINE PRICE IS ................ $72,400.00
