2024 DOOSAN SVM 5100L | Machining Centers, Vertical

DOOSAN VERTICAL MACHINING CENTER
MODEL: SVM 5100L, S/N: MV0175-000076, NEW: 2024

SPECIFICATIONS:
TABLE SIZE .................... 20" x 52"
TABLE CAPACITY ................ 1,764 lbs / 800 kg
X-AXIS TRAVEL ................. 50" / 1270mm
Y-AXIS TRAVEL ................. 20" / 510mm
Z-AXIS TRAVEL ................. 20" / 510mm
SPINDLE SPEED ................. 12,000 RPM
SPINDLE MOTOR ................. 25 hp
SPINDLE TAPER ................. CAT 40
TOOL CAPACITY (ATC) ........... 30
RAPID TRAVERSE RATE ........... 1,417 in/min.
APPROX MACHINE WEIGHT ......... 12,850 lbs
APPROX MACHINE DIMENSIONS ..... 87"L x 122"W x 106"H

EQUIPPED WITH:
DOOSAN-FANUC i SERIES PLUS CNC CONTROL
REMOTE JOG HANDLE
RENISHAW PROBE READY (EYE AND WIRING PRESENT,
PURCHASE OF PROBE TOOL REQUIRED
300 PSI THROUGH SPINDLE COOLANT
SPINDLE CHILLER
30 POSITION SIDE MOUNT TOOL CHANGER
CAT 40 TAPER
