78"/98" Momentum MVL-20HD CNC Vertical Boring Mill

SPECIFICATIONS:
Table Diameter 78.74"
Max Swing Diameter 98.42"
Max Turning Diameter 98.42"
Max. Turning Height, Std. Holder 82.67"
X-Axis Horizontal Travel -51.18" to 59.05"
Z-Axis Vertical Ram Travel 49.2"
Cross Rail Travel, 4-Steps 44.08"
Table Speeds, Two Ranges 13 to 200 RPM
Ram Stroke 49.2"
Ram Cross Sectional Area 10" x 10"
Cross Rail Travel, 3-Steps 29.52"
Maximum Table Weight Capacity 33,069 LBS
Automatic Tool Changer 12 Stations
Rapid Traverse Rate, X & Z Axis 393.7 IPM
Cutting Feed Rate mm/min 0.03937 ~ 78.74 IPM
Main Spindle Motor 100.5 HP / 80.4 HP
Electrical Rating 120 kva
MACHINE DIMENSIONS:
Overall Height 278"
Floor Space L x W 278" x 238"
Machine Weight 110,231 LBS



Equipped With:
Fanuc Oi-TF CNC Controls
78.74" Face Plate Chuck W/4-Jaws
12-Station Floor Mounted Automatic Tool Changer
Programable Cross Rail
Extended Column Height 11.81"


Note: Brand New In Shipping Crates!
Immediate Delivery
Installation Available!
1-Year Parts Warranty
