5′ x 5′ CAMaster Cobra Elite CR505 CNC Router, 2020 – Tool Changer, Dust Collector

Table Size: 5′ x 5′ Spindle: 12 HP HSD ATC Spindle ATC: 10 Tools Z Axis Clearance: 10″ Drive System: Helical rack and pinion Motors: AC servo motors with planetary gearboxes for high-speed performance Speed: 2,500 IPM; cut speed up to 1,500 IPM Table Top: Phenolic vacuum table Frame: Heavy-duty steel construction Controller: SmartCore Digital PLC Controller

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,15 HP FPZ Regen Vacuum Hold-Down System. Includes: 15 HP Regen Vacuum Pump. Pump runs off of 208-230/460 V 3 Phase Power. Safety Valve Inline Vacuum Filter Inlet Vacuum Filter Vacuum Gauge Vacuum Grided TableTop and Plumbing w/Valves for easy connection to Vacuum Pump Auto Relief Valve to Engage and Disengage Vacuum On Table Controlled Via G-Code

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With:

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Brushless AC Servo Drive System Dual Drive on Y Axis Z Axis Brake 2” Heavy Duty Precision Rails & Bearings on all Axis Industrial Steel Welded Frame All Steel Gantry All-Steel Gusseted Side Supports High Precision Planetary Gearboxes Helical Rack & Pinion Automatic Tool Measure Switch Custom Built Monitor Stand with On/Off, Cycle Start, Cycle Stop and E-Stop Buttons and USB Port High Speed Visual CNC Control System (WinCNC) Windows 10 PRO Control Computer Touch Screen Monitor, Keyboard, & Mouse V Carve Pro Design Software Upgraded to Phenolic Table Top
