Haas HRT-160 Rotary Indexer, 2022 – Only Tested Never Ran Production

Platter: Platter Diameter: 6.30 in (160 mm) Max Weight on Platter (w/support): 90 lb (40.8 kg) Max Weight on Platter (unsupported): 45 lb (20.4 kg) Number of Std T-Slots: 6 @ 60° (6 @ 60°)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Spindle: Max Speed: 130 °/sec (130 °/sec) Torque (Continuous): 150 ft-lbf (203 Nm) Runout Max: 0.0005 in (0.013 mm) Center Height: 5.000 in (127.00 mm) Backlash: 30 arc-sec (30 arc-sec) Brake Torque @ 100 psi/6.9 bar: 100 ft-lbf (136 Nm) Gear Ratio: 63:1 (63:1) Timing: 2:1 (2:1)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Indexing: Accuracy (±): ± 15 arc-sec (± 15 arc-sec) Repeatability: 10 arc-sec (10 arc-sec) Resolution: 0.001 ° (0.001 °) Worm Gear Dia: 4.7 in (119 mm) Max Rotation/Step (with rotary control): 999.999 ° (999.999 °)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,General: Power Requirement: 115 VAC ±10% @ 15 A (115 VAC ±10% @ 15 A) Operating Temp (max ambient): 100 °F (38 °C)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Air Requirements: Air Pressure Max: 150 psi (10.3 bar)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Dimensions – Shipping: Export Crate: 27.0 in x 21.0 in x 21.0 in (69 cm x 54 cm x 54 cm) Weight: 140 lb (64.0 kg)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
