22 Ton Amada EM2510NT Servo Electric CNC Turret Punch Press With MP1225 NJ Loader

CAPACITY:
Tonnage Capacity 22 Tons
Table Travel 50" x 100"
Throat Depth 52"
Maximum Material Thickness 1/8"
Maximum Punch Diameter 4-1/2"
Hit Rate 1" Pitch, .197" Stroke 500 HPM (X-Axis)
Hit Rate 1" Pitch, .197" Stroke 330 HPM (Y-Axis)
Hit Rate .040" Pitch, .197" Stroke 780 HPM (X-Axis)
Hit Rate .040" Pitch, .197" Stroke 515 HPM (Y-Axis)
Marking Speed 1800 HPM
Marking Speed 830 HPM
X-Axis Positioning Speed 3,950 IPM
Y-Axis Positioning Speed 3,150 IPM
Stroke Length 1.65"
Machine Weight 39,683 Lbs



Equipped With:
Fanuc AMNC-PC CNC Control
AC Servo Driven Punch Ram
Brush Table Design
58 Station Thick Turret (No Holders or tooling)
(2) 1-1/4" Auto Index Stations
Auto Sheet Repositioning
MP 1225NJ Loader


NOTE: Inspect Under Power in Plant
