18′ Nanxing MFB60CY Precision Edge Banding Machine, 2016 – Diamond Pre-Mill, Analog Adjustments
Brand
Category
Type
Model
MFB60CY
Stock #
903135
Year
2016
Condition
Not specified
Location
Not specified
|
Panel Thickness: 10-60mm
Panel Width (Minimum): 80mm
Panel Length (Minimum): 360mm
Edge Width: 15-65mm
Edge Thickness: 0.4-3
Feed Speed: 9-18 m/min
Pneumatic Power: 0.7MPa
Installed Power: 12.18 kW
Net Weight: 1750kg
Overall Dimensions: 4765x850x1380mm
Input Frequency: 50 Hz
Input Voltage: 380 V
Input Power: 7.9 kW
All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With: – Diamond Pre-Mill – Front and Rear Trimming – Rough and Fine Top and Bottom Trimming – Scraping and Buffing All specifications are assumed to be correct but must be confirmed by the purchasing entity. |
