Norstar Industries LGBE 3600 x 130ft Bucket Elevator System
Brand
Category
Type
Model
Norstar Industries LGBE 3600 x 130ft Bucket Elevator System
Stock #
476267
Year
2022
Condition
Not specified
Location
Not specified
|
CAPACITY: 150 TPH @ 60 LBS/FT3
RPM: 36
FPM: 345
MOTOR: WEG 40HP 2X4V324T TEFC
REDUCER: DODGE TA7315H25
BELT/CHAIN: 16″ x 600 PIW GR2 RUBBER BELTING
BUCKETS: AC 15 X 8 STEEL VENT #1
BUCKET SPACING: 10″
CONSTRUCTION MATERIAL: STEEL
MATERIAL THICKNESS: 10GA
HEAD CONSTRUCTION: STEEL 3/16″
HEAD SHAFT: Ø5.50
HEAD BEARINGS: SPW 2232-508 PILLOW B BEARING
BOOT CONSTRUCTION: STEEL 1/4″
BOOT SHAFT: Ø3.9375″
BOOT BEARINGS: UCPX20-63 PILLOW B BEARING
MAX CRANE CAPACITY: 1000LBS
DRIVE WEIGHT: 1300LBS
WEIGHT PER FOOT: 135LBS
NOTES: BUCKET CAPACITY RATED @ 85% WATER
LEVEL
All specifications are assumed to be correct but must be confirmed by the purchasing entity. |
