18" X 20" MARVEL SERIES 81A/9 TILT FRAME FULL AUTOMATIC VERTICAL BAND SAW: STOCK #23180
Brand
Category
Type
Model
Not specified
Stock #
23180
Year
Not specified
Condition
Not specified
Location
Ohio
Price
$14,500.00
|
SERIAL ............................ E-414488-W
MODEL ............................. 81A/9 CAPACITY .......................... 18" X 20" (18" ROUNDS)
CAPACITY AT 45 DEGREES ............ 18" X 13" (13" ROUNDS)
BLADE SPEEDS ...................... 60 TO 400 FPM (VARIABLE)
POWER FEED TO HEAD ................ 0# TO 300#
DUAL HYDRAULIC VISES .............. YES
HEAD TILTS 45 DEGREES ............. RIGHT AND LEFT HYDRAULIC
LENGTH OF BLADE ................... 14'6" X 1-1/4"
LENGTH OF STOCK STROKE ............ 0 TO 24"
HYDRAULIC BLADE GUIDE ............. YES
HYDRAULIC ROLLER LIFT ............. BOTH SIDES
WORKING SURFACE OF TABLE .......... 30" X 33"
STOCK FEED TABLE .................. YES
EXIT & ENTRY CONVEYOR ............. YES
CAPACITY ON SHUTTLE FEED TABLE .... 7,000 LBS
COOLANT WITH CONVEYER CLEAN OUT ... YES
MAIN HYDRAULIC MOTOR .............. 7-1/2 HORSEPOWER |
