Feed Line, Servo, Dallas, 72" x 0.060"

YEAR: 1998

Consisting of the following:

-Dallas DJR-20,000# x 72" Coil Reel:
Serial Number: 20212
20,000 lbs.
72" Wide
20" - 24" ID
72" Max. OD
Powered Jog Forward and Reverse
6 Keepers

-20,000# Dallas LC-20,000# x 72" Coil Lift:
Serial #20213
42" Min. OD
72" Max OD
18" Lift Height

-Dallas DPS-4 1/4-7-72 Powered Straightener:
Serial #20215
72" x 0.060" Mild Steel
48" x 0.125" Mild Steel Capacity
7 Straightening Rolls, 4.25" Diameter Rolls
Entry and Exit Pinch Rolls
Coil Restrictor-Debender, Peeler-Threader
Dual Exit Threading Tables
Hand Held Pendant
Sona-Trol Loop Eye

-Dallas DRF-672 Servo Feed:
Serial Number: 20217
72" x 0.060" Mild Steel
48" x 0.125" Mild Steel Capacity
6" Diameter Feed Rolls
Control Updated in 2015 DRF Control 900E
Hand Held Pendant
Adjustable Cabinet Base
480V / 3 PH / 60 HZ
Right to Left Direction

-Approx. Weight: 18,000 lbs.

-Removed and in Storage: IL.
