Pallet Size: 15.75″ x 15.75″ Number Of Pallets: 6 Pallet Indexing: Full 4th Axis X Axis Travel: 22″ Y Axis Travel: 22″ Z Axis Travel: 24.6″ Rapid Traverse: 2,362 IPM Spindle Taper: CAT 40 Big Plus Spindle Speed: 15,000 RPM Spindle Motor: 40 HP ATC: 146

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With:

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Okuma OSP P300 Control 6 Pallet Pool System (Added in 2022) 200 Hour Lube Tank Extended Cap Drain Tank 146 Station ATC Ext Tool Length, 400MM Shower Coolant Tool Breakage Detection EXT Common Variables (1000 Sets) M-Codes 4 Spare Message Function Mid Block Restart Tool Offsets Work Coordinates Dual Belt Chip Conveyor Prep for Mist Collector Auto Gauging Renishaw RMP60 Probe ATS Cooljet 1000 PSI Mist Collector

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
