X, Y, Z Axis Travel 60 x 26 x 24 in B, C Axis Travel +/- 92°, 360° Spindle Nose to Table (Min-Max) .5 / 24.5 in Table Size 66 x 26 in Table Size C 23.6 in diameter Max. Weight on Table 3,000 lbs Max Weight on Rotary/ Trunnion Table 1,100 lbs Spindle Max. Spindle Speed 16,000 rpm Tool Changer CAT-40 Number Of Tools 40 Max Tool Diameter 2.95 in (75 mm) Max Tool Length 9.8 in (249 mm) Max Tool Weight 15.4 lb (7 kg) Max. Operating Floor Space 222.9 x 154.4 in Machine Height 129.8 in Machine Weight 23,980 lb

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With: WinMax CNC Control 300 psi Coolant Thru Spindle 16,000 RPM spindle 3D Import includes DXF Tool & Material Library UltiPockets NC/Conversational Merge Renishaw RMP 60 Part Probe & RTS Tool Probe Mist Collector

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
