Power Requirements: 200-240VAC 1 PH 50/60 Hz Cutting Envelope: 5′ x 10′ Clearance Under Gantry Beam: 5″ Linear Guides on Cross Axis Gantry Bridge: 1.18″ Linear Guides on both Rail Axes: 1.18″ Table Slat Height: 32″ Rapid Traverse Speed: 1,200 Ipm Machine Dimensions: 8.33′ x 13.75′ Machine Weight: 7,500 lbs.

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With MAXPRO200 Power Supply Plasma marking Collision sensor Refrigerated air dryer Consumables kit Two gas regulators for shield gasses ProNest LT 2025 software Hornet’s Crosshair Laser System for quick and easy homing and plate alignment Movable control console with 21” touchscreen interface Water table with quickly adjustable water level via ballast tank Zoned Downdraft table available at the same cost as a water table Factory installation and operator training

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
