Haas VF-3 VMC, 1993
Brand
Category
Model
VF-3
Stock #
Not specified
Year
1993
Condition
Not specified
Location
Not specified
|
X-Axis: 40″
Y-Axis: 20″
Z-Axis: 25″
Length: 48″
Width: 18″
Max. Weight On Table: 3,500 lbs
T-Slots Width: .625″
T-Slots Center Distance: 3.15″
Taper Size: CT40
Speeds: 50 To 7,500 RPM
Ratios: 11.25 High, 3.2 1 Low
Bearings: ABEC Class 7
Bearing Lubrication: Air / Oil Injection
X, Y, Z: 500 IPM
CNC Control: Haas Control
Tool Magazine: 20 Tools
Machine Dimensions (LXWXH): 118″ X 110″ X 119.5″
Machine Weight: 12500lbs
Toolholders: CAT 40 Taper
All specifications are assumed to be correct but must be confirmed by the purchasing entity. |
