1/4″ x 10″ Adira GHS-0630 Hydraulic Power Squaring Shear, 1999 – Backgauge, Squaring Arm

Maximum Cutting Thickness: 1/4″ Maximum Cutting Length: 120″ Back Gauge Depth: 29″ Number Of Hydraulic Holddowns: 16 Blade size: 0.25″ x 2.5″ x 122″ Throat Depth: 12″ Table Height: 34″ Rake Angle, Fixed: 1-1/4 Deg Gap adjustment(12): .002” – .043” Main Motor: 12 HP Electrics: 220/440 V, 3 PH Electrics, As currently Wired: 440 V, 3 PH Approx. Dimensions, No Arms: 140” x 68” x 69” Approx. Weight: 12,350 lbs

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,EQUIPPED WITH:

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Adiramatic 2011 Self Positioning Back Gauge Control Readout 40″ Back Gauge with LED Squaring Arm Adjustable Stroke Length Infinitely Variable Blade Gap Adjustment Flush Floor (No Pit)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
