Graffenstaden X: 2500 - Y: 630 - Z: 1000mm

Brand
GRAFFENSTADEN
Category
CNC, Metalworking & Manufacturing
Type
Milling Machines
Model
X: 2500 - Y: 630 - Z: 1000mm
Stock #
B.03 9737
Year
Not specified
Condition
Not specified

Location

Not specified
REQUEST FINANCING
Located in Deinze, Belgium

Technical information

  • Longitudinal travel X-axe 2500 mm
  • Cross travel Y-axe 630 mm
  • Travel Z-axe 1000 mm
  • Dimensions clamping space- table 3100 x 630 mm
  • Max height workpiece 825 mm
  • Power on spindle 15 HP
  • Admission in millinghead (ISO) ISO 50
  • Max speedrange 16 > 800 rpm
  • Length 4730 mm
  • Depth 3200 mm
  • Height 2400 mm
  • Weight 11 ton

Additional info

  • Type: FB625SD
