Fadal EMC VMC, 2004 – 15 Station ATC
Brand
Category
Model
EMC VMC
Stock #
663657
Year
2004
Condition
Not specified
Location
Not specified
|
Y Axis Travel: 20″
X Axis Travel: 16″
Z Axis Travel: 14″
Spindle Motor: 12 HP
Spindle Speed: 7,500 RPM
Spindle Taper: 40 CT
Tool Changer: 15 ATC
Rapid Rate X Axis: 700 IPM
Rapid Rate Y Axis: 700 IPM
Rapid Rate Z Axis: 700 IPM
Table Size: 29.5″ x 16″
Dimensions: 80″ x 75″ x 92″
Weight: 4,800 LBS
Max Table Load: 1,000 LBS
All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With: Multi Processor CNC Control All specifications are assumed to be correct but must be confirmed by the purchasing entity. |
