Core Cutter, Appleton, 6" x 10' STOCK# 3843

Model:  A400

-Serial Number:  051211B is a 3" Unit with 3" Tooling and will come with
  a used 6" gripper but no 6" Sleeve to make it 3" and 6" capable with the
  addition of a 6" sleeve.

-Master Core Length:  96" Max.

-Capable of 1.5", 3" & 6" Cores Dia.

-High Speed Single Knife Cutting.  The A400 is Appletons fastest single
  knife re-cutter, running up to 2 times faster than the A-301.

-This unit serves to rapidly cut batches of fiber cores of a given length
  with minimum operator labor and to cut heat sensitive and/or thick
  wall plastic tubes & tapes.

The A400 provides you with:

-Faster cutting - the result of an improved hydraulic system coupled with
  our fixed knife.

-Clean, polished, cuts - The Appleton fixed knife slices rather than saws
  or scores for a cleaner, faster cut.

-Precise Control - new valving results in a wider range of operator adjustment
  offeed and cutting rates for optimal performance.

-Plastic Cutting - with proper cutting tools the A400 can cut a variety of
  plastics.

-Expandability - The A400 is PLC equipped, making it ready for automation
  options like the auto-indexing knife or automated parent and cut core
  handling systems - freeing your operators for other tasks.

-Quick Diameter Changes - Five minutes for a mandrel change, or less than
  one minute with our patented Instant Diameter Change (IDC) mandrel system.

-Energy Savings - The A400 has a timer that shuts down the cutter if it has
  not been used for an operator settable interval.  This saves wear and tear
  on the cutter.

-Improved Safety - The cutter is running only when it is in service, the
  knife is well guarded.

-Service Prompt - The A400 prompts the operator when it is time to service
  the hydraulic filter.

Specifications:

-Cut Length Range:
  -5' to 8' in 1 foot increments.
   Note:  the core I.D.'s under 3" limit machine length to 10'.

-Core Diameter Range:
  -3" ID to 13" OD
   with options this range can be expanded down to 1" I.D. and up to
   21" O.D.

-Wall Thickness:
  -.250" to .625" (includes .660" cores)
   with options the wall thickness range can be expanded to
   0.125" to .750".  For heavier walls contact Appleton Mfg.

-Minimum cut determined by core integrity (typically equal to wall thickness)

-Maximum Length:  Reference standard cut length in Appletons Chart:
  Should be 60" Extended
  Maximum Length 96"

-Cut Length Tolerance:
  +/- 0.010" (3 Sigma)

-Utilities:
  3 Phase Electrical Power
  Voltage:  440V
  80 PSI Air
  1 SCFM @ 50 cuts/minute (cut rate, operator and core dependent)
  Hydraulic Power Unit:  3 HP, 230/460V
