Hwacheon Vesta 1000+ VMC, 2021 – Fanuc Control, 12,000 RPM spindle, 30 ATC
Brand
Category
Model
Vesta 1000+
Stock #
735934
Year
2021
Condition
Not specified
Location
Not specified
|
X Axis Travel: 39.3″
Y Axis Travel: 21.653″
Z Axis Travel: 19.68″
Rapid Rate X Axis: 1,414 IPM
Rapid Rate Y Axis: 1,414 IPM
Rapid Rate Z Axis: 1,179 IPM
Table Size: 43.3″ x 19.685″
Max Table Load: 1,540 LBS
Spindle Motor: 25 HP
Spindle Speed: 12,000 RPM
Spindle Taper: 40 BT
Tool Changer: 30 ATC
Dimensions: 88″ x 97″ x 112″
Weight: 26,000 LBS
All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With: Fanuc Oi-MF Plus Control Side or rear-mounted swarf conveyor Spindle Chiller All specifications are assumed to be correct but must be confirmed by the purchasing entity. |
