Throat: 36″
Maximum Height under Blade Guide: 10″
Main Table:
Size: 30-1/2″ x 30-1/2″
Tilt:
35 Degrees Forward
10 Degrees Left, Right & Rear
Inboard Extension Sub Table:
Size: 16-3/4″ L-R x 20″ F-B
Blade Speeds: 0 to 1600 FPM
Blade Speed Ranges: via High/Low Transmission
Blade Width: 1/16” to 1-1/4″
Blade Length: 192″
Motor: 1 HP, 1725 RPM
Approximate Overall Dimensions: 78″ Wide x 36″ Deep x 76″ High
Approximate Weight: 2,800 lbs.
All specifications are assumed to be correct but must be confirmed by the purchasing entity. |
