Make: SCM Type: Sigma Prima PLM Panel Saw Year of construction: 2002

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Technical Data: Main motor power: 7 kW Cutting length: 3,300 mm Cutting height: 60 mm Saw blade projection: 67 mm Collets: 5 pieces Main saw blade: 320 mm Scoring saw blade: 160 mm Saw carriage feed forward: 0-80 m/min Saw carriage feed, return: 0-80 m/min Program slide feed forward: 0-25 m/min Program pusher feed, return: 0-50 m/min Air cushion tables: 3 Scoring unit: 1.3 kW Control: PC/PLC with M258 unit Software: Wincut 12 Dimensions: 8,600 x 5,700 x 2,150 mm Weight approx. 4,760 kg Lifting table dimensions: 3,300 x 1,850 mm Lifting table with motorized loading rollers for double-sided loading Cut optimization program “Cutty” Quick clamping system for the saw blades with a pneumatic blocking device Laser alignment light on kerf

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Note: The technical data and descriptions are a copy of the order confirmation at the time. Data is for information only and is not binding.
