60″x 120″ Multicam 3204-R CNC Router, 2006

Table: 60×120 Table Motor: 4.0 HP Perske Spindle Spindle Speed: 24,000 RPM Z-Axis Clearance: 6″ – Optional 10″ Z-Axis Travel: 12″ Repeatability: +/- .001″ Positional Displacement Accuracy:+/- 0.005″ over 10 feet Maximum Cutting Speed: 1,400 ipm * Maximum Rapid Traverse: 2,500 ipm * Drive System X and Y axis: Rack and Pinion Drive System Z axis: Ball Screw Standard Work Surface: 1″ Phenolic Machine Weight: 5,170 lbs

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Equipped With: 10 HP Positive Displacement Vacuum Hold Down System 4 Valved & Zoned Phenolic Grid Tabletop Automatic Misting/Lubrication system (for metal routing) EnRoute 3 Plus Routing Tool Path Software Chip Vacuum Extraction System

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
