Jyoti TS 120 Twin Spindle CNC Chucker Lathe, 2016 – Twin Turret, Auto Loader

Slides X-Axis Travel: 3” Z-Axis Travel: 5.7” Rapid Feed (X & Z axis): m/min 24

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Main Spindle No. of spindles 2 Spindle Motor Power – Siemens kw 8.3/5.5 Spindle Motor Power – Fanuc kw 7.5/5.5 Spindle Speed Range rpm 50-4500 Spindle Nose A2-5

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Turret Number of Turret 2[16(8+8)] Indexing Time: sec 05

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Capacity Chuck Size: 6.5” Work Piece Dimension (Loader Capacity): 4.7″ x 3.1” Automated Gantry Robot Loader/Unloader Max. Part Weight (No. of Parts) kg 3(2) Loader X (Left/Right) Axis Stroke: 72.8” Max. Speed (X-Axis) m/min 120 Loader Y (Up/Down) Axis Stroke 22” Max. Speed (Y-Axis) m/min 90 Loader Z (Front/Rear) Axis Stroke: 6” Max. Speed (Z-Axis) m/min 50 Standard Loading Time sec. 7

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Accuracy (As per VDI/DGQ 3441) Positioning Uncertainty (P) mm 0.007 Repeatability (Ps medium) mm 0.005

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Other Data Machine Weight # (Approx.): 10,000 Machine Dimension # (Approx.) Length 85” Width: 75” Height: 95”

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
