5″x5″x1/2″ Imcar CPHV 120 Double Initial Pinch Universal Hydraulic Angle Bending Roll, 2007

Imcar (Carel) Model Cphv-120 Flats, Hard: 5” X 7/8” Ø 60” Flats, Easy: 8” X 2” Ø 48” Square Bar: 3” Ø 36” Angle, Leg-Out: 5” X 1/2” Ø 65” Angle, Leg-In: 4” X 1/2” Ø 48” Tee, Leg-Out: 4-1/2” X 1/2” Ø 50” Tee, Leg-In: 4” X 1/2” Ø 50” C, Leg-Out: 8” X 3” Ø 35” C, Leg-In: 8” X 3” Ø 48” Round Bar: 3-3/8” Ø 40” 1 Pipe, Schedule 40: 4 Ø 60” Schedule 80 1 Round Tube: 6” X 10 Gauge 2 Square Tube: 3-1/2” X 5/16” 2 Rectangular Tube: 5” X 2-1/4” I-Beam, Easy Way: S7 X 20” Ø 32 H-Beam, Easy Way: W5 X 19” Ø 50 3 C, Hard Way: C5 X 9” Ø 110 3 I-Beam, Hard Way: W4 X 13” Ø 50 Rolling Speed: 0-22 Horse Power: 20 Roll Diameters: 15.375” Weight: 10,000 Lbs

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,Features Dual Led Digital Displays Rugged, Rigid, One Piece Solid Steel Weldment Frame 3 Shafts Driven/3 Direct Coupled Hydraulic Motors Larger, High Strength Steel Shafts Hydraulic Power Unit Multi-Axis, 6-Way, Fully Adjustable Lateral Guides Variable Speed Rotation Universal Bending Rolls With Modular Components Operate Both Horizontal And Vertical

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
