Emmeci MC 92 HSB (DX) Fully Automatic Rigid Box Line, Right-Hand Wrapper Discharge

Fully Automatic Lines to Manufacture Rigid Boxes

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Maximum size of paper wraps L x W: 850 x 490 mm (33-15/32 X 19 19/64”) -Minimum size of paper wraps L x W: 180 X 95 mm (7 1/8 X 3-3/4”) -Finished box lengths: 125 to 450 mm (4 15/16 to 17 3/4”) -Finished box widths: 35 to 305 mm (1 3/8 to 12 1/64”) -Finished box height: 12 to 80 mm (½ to 3 5/32”)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Achievement of production speeds up to 3000 pieces per hour (50 pieces per minute) dependent upon materials and finished box sizes

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Spotting accuracy of plus or minus 0.25 mm (1/100 of an inch)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Sub-straight pile height in Quad Stayer up to 1,400 mm (approximately 55”) dependent upon board thickness

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Maximum heat seal stay tape reel capacity: 400 mm (15 3/4 inches)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Pile capacity on gluer label table: approximately 4000 wraps

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Glue mixer overall capacity: 65 liters (17 U.S. gallons)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Set-up time of entire line with fully trained skilled operator: approximately one hour

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Overall complete line dimensions L x W: 6,900 x 4,000 mm (271 9/16 x 157 3/8 in.)

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Total electrical power: 16.63 Kw

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,-Air supply: 10 liter per hour, 5-8 bar, 0.35 CFM, 75-110 psi

All specifications are assumed to be correct but must be confirmed by the purchasing entity.,**More Information Upon Request**
