Waldrich 120" Diam. 50 Ton Capacity B-Axis CNC Rotary Table

Brand
WALDRICH
Category
Tables
Type
Tables, Rotary
Model
50 Ton Capacity
Stock #
30165
Year
1980
Condition
Not specified

Location

Not specified
REQUEST FINANCING
SPECIFICATIONS:
Table Diameter (Round) 120"
Table Rotary, B-Axis 360,000
Table Speeds (Inf. Variable) .0024 - 1.26 RPM
Table Gear Range, Number 3
Speed Range (1) .0024 RPM
Speed Range (2) .16 RPM
Speed Range (3) 1.26 RPM (Rapids)
Table Work Height 30"
Table Loading Capacity 50 Ton
Table Motor (3-Phase) 20 HP / 10 HP



Equipped With:
3-Step Automatic Gearbox
Clockwise & Counter Clockwise Operation
Gear Pinion Drive
Hydraulic Clamping


NOTE: Table Can Be Used For Turning & Positioning Operations


NOTE: New Electric Clutches Installed 2023
