60" x 1/4" x 30,000K HERR VOSS CUT TO LENGTH LINE
Brand
Category
Type
Model
Not specified
Stock #
116454
Year
Not specified
Condition
Used
Location
Not specified
|
60" x 1/4" x 30,000K HERR VOSS CUT TO LENGTH LINE Manufacturer: Herr-Voss
Yield Strength: 50,000 PSI
Width Capacity: 12" - 60"
Thickness: .020 - .250"
ID Range: 19.5" - 24"
OD Range: 24" - 84"
Length Capacity: 2- 20' Max Prime (40' Max - Special Handling)
Weight Capacity: 30,000 Lbs.
Pack Height: 24" Max Including Skids (Prime Piler)
12" Max Including Skid (Reject Piler)
Line Speed: 200 FPM
Jog Speed: 50 FPM
Line Direction: Left to Right
Line Includes:
Entry Four Arm Turnstile
Floor Type Coil Car
Uncoiler w/ Hold Down Roll
Peeler Table
Pinch Rolls
HV Keystone Leveler #1
72/3.000-17-5 5HI LH
HV Keystone Leveler #2
-72/1.750-19-7 6HI
Conveyor
Looping Pit w/ Roller Quandrants
Side Guide Unit
Roll Feeder w/ Measuring
Paper Winder w/ Feeder
HV High Speed Shear
Shear Run-Out Conveyor
Air Float Stacker
Discharge Conveyor
|
