NEW Minster P2H-160-63×33-FW Precision Straight Side Press
Brand
Category
Model
P2H-160-63×33-FW
Stock #
1048165
Year
2024
Condition
New
Location
Ohio
| SPM | 300 |
| Tonnage | 180 tons |
| Stroke | 2.95 inches |
| Shut Height | 17.7199 inches |
| Vari Speed (Yes/No) | yes |
| Bed W | 33.5 inches |
| Bed L | 63.0 inches |
| Crank (Single/Double) | double |
|
SPECIFICATIONS
Press Specifications Model Number........................................................ P2H-160-63×33-FW Force × Distance off Bottom.................................. 180 ton × 0.118 in Crankshaft Extension Location............................... Opposite Drive Side Drive Arrangement.................................................. Flywheel Drive Location........................................................ Left Hand Side Lube Unit Location................................................. Opposite Feed Side Approximate Press Weight..................................... 67,000 lb Shutheight Indicator Readout................................. Inch Shop Air Pressure, Minimum.................................. 85 psi Press Slide Specifications Stroke Length, Speed Range................................... 2.95 in, 70 - 300 spm Shutheight Adjustment........................................... 3.94 in Quick Access Slide Range...................................... 0.50 - 4.50 in Area of Slide, R-L × F-B........................................ 63.0 × 33.5 in Slide Face Machining.............................................. Standard
Press Bolster Specifications Bolster Plate Material.............................................. Steel Bolster Plate Thickness........................................... 4.92 in Area of Bolster, R-L × F-B..................................... 63.0 × 33.5 in Opening in Bolster, R-L × F-B............................... 51.2 × 9.8 in Bolster Plate Machining.......................................... Standard
Press Frame Specifications Upright Passline Opening, F-B............................... 24.8 in Area of Bed, R-L × F-B.......................................... 63.0 × 33.5 in Opening in Bed, R-L × F-B.................................... 51.2 × 14.6 in Bed Deflection at 67% of Die Area........................ 0.0012 in/ft Shutheight, Maximum (SDAU).............................. 17.72 in, on Bolster Approx Clearance, Mount to Bottom of Bed......... 11.8 in Approx. Distance Mount to Top of Bolster............ 46.4 in Approx. Distance Mount to Top of Bed................. 41.5 in Approx. Floor Area, R-L × F-B.............................. 132 × 80.0 in Approx. Overall Area, R-L × F-B........................... 132 × 80.0 in Approx. Overall Height, from Mount..................... 160 in |
|
